Top 10 Atomic Force Microscopy Companies Redefining Surface Science
Author : Aparna | September 4, 2024
Atomic Force Microscopy (AFM) is an advanced imaging technique that has revolutionized the study of surfaces at the nanoscale. By employing a sharp probe that scans the surface of a sample, AFM allows scientists to visualize and measure the topography and properties of materials with remarkable precision, often down to the atomic level. According to Kings Research, the global atomic force microscopy market is estimated to hit a valuation of USD 1,048.9 million by 2031. This blog discusses the top 10 companies involved in this niche based on their innovative product offerings and global presence.
What is atomic force microscopy?
Atomic force microscopy machine is an advanced imaging technique within the realm of scanning probe microscopy (SPM). Introduced in 1986 by Gerd Binnig, Christoph Quate, and Wolfgang Gerber, AFM has become a crucial instrument in nanotechnology and materials science.
The technique involves scanning a sharp probe, or tip, over a sample's surface to measure the forces between the tip and the surface at the atomic level. This interaction produces high-resolution three-dimensional topographical maps, revealing details on the nanometer scale, often with resolutions exceeding 1 nanometer.
What is the principle of atomic force microscopy?
Atomic Force Microscopy (AFM) is based on an intermolecular force measurement between a pointed probe and a sample surface. In essence, AFM utilizes a cantilever with a sharp tip that scans the surface of a sample.
The approach of the tip toward the surface induces intermolecular forces—van der Waals forces, electrostatic forces, and mechanical forces—that give rise to cantilever bending. A laser beam is employed to detect cantilever bending by reflecting the beam of the cantilever and onto a photodetector surface. This provides a direct measurement of the tip micromovement as a function of the features of the surface.
AFMs can operate in various modes, such as contact mode, where the tip makes direct contact with the surface, and non-contact mode, where the tip hovers above the surface without making contact. In contact mode, the deflection of the cantilever is continually recorded in real-time, and feedback is utilized to allow the system to maintain a constant force applied to the sample by the tip. This feedback loop accomplishes high-resolution topographical imaging at the nanoscale and can achieve resolution measurements down to fractions of a nanometer.
Top 10 atomic force microscopy companies paving the world in 2024
1. Park Systems
Park Systems is a leading provider of atomic force microscopy (AFM) solutions, renowned for its advanced nanometrology technologies. The company offers a wide range of AFM systems designed to meet the diverse needs of research and industrial applications, helping scientists and engineers push the boundaries of nanoscale research.
In 2021, Park Systems launched the Park FX40, an innovative autonomous AFM that incorporates advanced robotics and artificial intelligence. This groundbreaking AFM is designed to automate setup and scanning processes, significantly improving efficiency and accuracy in nanoscale research.
2. Hitachi High-Tech Corporation
Hitachi High-Tech Corporation, a subsidiary of Hitachi Ltd., specializes in high-tech solutions, including electron and optical systems. Their portfolio includes advanced atomic force microscopes tailored for both research and industrial applications.
Hitachi High-Tech has enhanced its AFM offerings like AFM500 Pro with advanced software integration for improved imaging and data analysis. This innovation aims to increase the usability and precision of AFM technology in semiconductor and materials science research.
3. Nanonics Imaging Ltd
Nanonics Imaging Ltd is known for its innovative contributions to AFM and near-field scanning optical microscopy (NSOM). The company offers integrated solutions that combine AFM with other high-resolution imaging techniques.
4. Bruker
Bruker is a prominent name in scientific instruments, offering a comprehensive range of AFM systems. Bruker’s AFMs are widely used in various fields, including materials science, biology, and nanotechnology.
In January 2022, Bruker launched a cutting-edge BioAFM system designed to revolutionize the field of mechanobiology. This advanced atomic force microscopy (AFM) tool offers high-speed automated measurements, significantly enhancing the ability to study the mechanical properties of biological samples at the nanoscale.
5. Keysight Technologies
Keysight Technologies specializes in electronic measurement solutions and offers advanced AFM systems that integrate with their broader suite of electronic and optical measurement tools.
Keysight recently updated its AFM platform with enhanced imaging modes and a new control system that allows for faster and more precise measurements, catering to the needs of semiconductor and life science research.
6. Oxford Instruments
Oxford Instruments provides a range of high-tech tools for scientific research, including advanced AFM systems. They focus on delivering solutions that combine AFM with other analytical techniques for comprehensive material analysis.
The company has developed an advanced AFM system with enhanced resolution and sensitivity, specifically designed for applications in quantum materials and nanotechnology.
7. Nanosurf
Nanosurf is a key player in the AFM market, known for its compact and user-friendly AFM systems. Their instruments are widely used in both educational and research settings for nanotechnology and materials science.
8. Horiba, Ltd.
Horiba, Ltd. is a diversified technology company that provides analytical and measurement instruments, including AFM systems. They are well-regarded for integrating AFM with Raman spectroscopy for comprehensive material analysis.
In 2023, Horiba introduced a new AFM-Raman hybrid system that offers high-resolution topographical imaging combined with detailed chemical analysis, targeting advanced research in materials science and nanotechnology.
9. NT-MDT Spectrum Instruments
NT-MDT Spectrum Instruments specializes in AFM technology, providing advanced tools for high-resolution imaging and surface analysis. Their products are used globally in scientific research and industrial applications.
NT-MDT unveiled a new AFM model featuring enhanced sensitivity and a broader range of operational modes, designed to meet the evolving needs of nanoscience research.
10. Semilab Inc.
Semilab Inc. is a leader in metrology solutions, offering specialized AFM systems for semiconductor manufacturing and material characterization. Their tools are designed to provide precise surface measurements and defect analysis.
In 2023, Semilab developed a next-generation AFM system that integrates optical and electrical measurement capabilities, aimed at providing comprehensive analysis solutions for semiconductor research and development.
Winding Up
Atomic force microscopy imaging stands out as a powerful and versatile tool that enables researchers to explore the nanoscale world with exceptional precision. Its ability to provide detailed topographical information and assess material properties under various conditions makes it invaluable across diverse fields, including materials science, biology, and nanotechnology. As advancements in AFM technology continue to emerge, its applications will likely expand, driving further innovations and discoveries in understanding complex materials and biological systems.
